Understanding Container Train Cars and Their Uses

Container train cars are a crucial part of modern transportation, allowing for the efficient movement of goods across the country. They're essentially large metal boxes on wheels that can be easily loaded and unloaded.

A standard container train car is typically 53 feet long and 8 feet wide, with a height of around 9 feet. This size is designed to fit standard shipping containers.

These train cars can carry a wide range of goods, from electronics and machinery to food and clothing. The versatility of container train cars makes them a vital part of the global supply chain.

In terms of capacity, a single container train car can hold up to 53,000 pounds of cargo.

You might enjoy: Alaska Car Transport Tacoma Port

Well cars can be 40-foot or 53-foot in length. A 40-foot well car can accommodate a single 40-foot container in the well, or two 20-foot containers.

A 53-foot car can hold a single 40-, 45-, 48-, or 53-foot container in the well. If you look on the side of some well cars, you'll find the various container lengths indicated.

In some cases, 53-foot containers are placed on top of 40-foot containers in a specific pattern to avoid overhang issues. On 40-foot, three-unit articulated well cars, 53-foot containers are usually placed on top in the A and B units.

Take a look at this: Car Shipping Companies from Us to Canada

Conventional intermodal railcars are a common type used for shipping containers. They're great for trailers and containers that can't be stacked due to route height restrictions.

These railcars are articulated, meaning they share wheels between cars, which helps reduce slack between cars. Slack action is basically how much movement one car has before its motion affects an adjoined car.

The articulated feature improves ride quality and makes for a less bumpy trip for fragile cargo. This is especially important for shipping containers that need to be handled with care.

Sizing on these railcars can vary, from around 50 feet to over 80 feet in length.

For your interest: How Do Shipping Containers Lock Together

Well cars are specialized railcars designed to transport stacked shipping containers, and they come in various sizes. The most common size is 40 feet, but you can also find 53-foot well cars.

These railcars have wells that reduce the height of stacked containers and lower the center of gravity, making them more stable and secure. Wells also improve security by surrounding the bottom container with walls, preventing the door from being opened while on the railcar.

A fresh viewpoint: Portable Storage Containers for Rent in St. Louis

The size of the container that fits in the well depends on the type of well car. A 40-foot well car can accommodate two 20-foot containers or a single 40-foot container, while a 53-foot well car can hold two 20-foot containers or a single 40-, 45-, 48-, or 53-foot container.

The overhang of a 53-foot container on top of a 40-foot well car can be handled in different ways, such as alternating 40- and 53-foot containers or placing a 53-foot container on top in one unit and a single container in adjacent units.

The placement of 53-foot containers on top of 40-foot well cars also depends on the configuration of the railcar. On 40-foot, three-unit articulated well cars, 53-foot containers are usually placed on top in the A and B units, while on 40-foot, five-unit articulated cars, they're placed on top in the A, B, and D units.

Some well cars, like the NSC Super Stack, can swallow four fully loaded 20-foot containers or one 40 to 48-foot container in their well, plus a 40- to 53-foot container stacked on top.

Double stack intermodal railcars are a game-changer for efficiency in container transportation. They can haul two shipping containers stacked on top of each other, maximizing the amount of cargo that can be transported.

The use of wells on these railcars is a clever design feature that reduces the height of stacked containers and lowers the center of gravity, making them more stable and secure. This is especially important for fragile cargo.

By customizing the size of the railcars to fit different types of containers, double stack intermodal railcars can efficiently transport containers of all sizes, from 20 feet to 50 feet and larger.

Discover more: Ocean Freight Tracking

Container efficiency is key to maximizing cargo transportation. Double stack intermodal railcars can carry a second shipping container on top of the first, allowing for a greater amount of cargo transportation.

These railcars utilize wells, which reduce the height of stacked containers and lower the center of gravity, avoiding problems with height restrictions along routes and creating more stability. Wells also improve security for containers by surrounding the bottom container with walls, making it impossible to open the container door while it is on the railcar.

The NSC Super Stack is a 100-ton, double stack container car with a 48-foot, 2-inch-long well. This behemoth can swallow four fully loaded 20-foot containers or one 40 to 48-foot container in its well, plus a 40- to 53-foot container stacked on top for a staggering load limit of 226,000 pounds.

Each well is equipped with full draft pockets, self-contained air brakes, operating truck-mounted brakes, and a handbrake. Wide platforms provide easy access to the container corners for installation of inter-box connectors and for servicing refrigeration units.

Time to accelerate, indeed. Tatravagónka brought a high-speed wagon to Innotrans 2024, capable of 160 km/h, a significant increase from the standard 120 km/h.

This new wagon has the potential to revolutionize container train transportation. It could allow for fast container trains that can run during the day without disrupting passenger traffic too much, making it a serious alternative to air cargo and road transport.

The introduction of such a wagon would be a game-changer, enabling faster and more efficient transportation of goods.

The container train car industry is rapidly evolving, and there are some exciting developments to share.

The Association of American Railroads (AAR) reported a significant increase in intermodal container traffic in 2020, with a 12% rise in container carloads.

Railroads are investing heavily in new technology to improve efficiency and safety.

The AAR also noted that the average age of the North American rail fleet is decreasing, with many railroads replacing older cars with newer, more efficient ones.

The introduction of double-stacked container cars has increased rail capacity and reduced transportation costs for shippers.

According to the AAR, the use of double-stacked cars has increased by 25% over the past five years.

A 40-foot well car can accommodate a single 40-foot container in the well. This is a common configuration.

A 53-foot well car can hold a single 40-, 45-, 48-, or 53-foot container in the well. This flexibility is useful for container trains.

The side of some well cars indicate the various container lengths they can accommodate. This includes DTTX 787478, which shows the different lengths.

On 40-foot articulated well cars, 53-foot containers can be placed on top in an alternating pattern with 40-foot containers. This helps with overhang.

In some cases, a 53-foot container is placed on top in one unit and a single container is placed in adjacent units. This is a solution to the overhang problem.

On 40-foot, three-unit articulated well cars, 53-foot containers are usually placed on top in the A and B units. This is because these units have non-articulated trucks and additional space.

On 40-foot, five-unit articulated cars, 53-foot containers are normally placed on top in the A, B, and D units. This takes advantage of the additional space in these units.
