Small blister pack machines are a popular choice for flexible packaging solutions, especially for pharmaceutical and cosmetic products. They offer high-speed packaging and minimal waste.
These machines can produce a wide range of blister packs, from small pill packs to larger tablet packs. They're perfect for small to medium-sized businesses that need efficient packaging solutions.
The compact design of small blister pack machines makes them ideal for use in small production facilities or pharmacies. They're also relatively low-maintenance, which is a big plus for businesses with limited resources.
Technical Details
The technical details of a small blister pack machine are just as important as its functionality. The machine's power consumption can range from 2.75KW to 4.0KW, depending on the model.
The WM-DLL160 model, for instance, has a power consumption of 2.75KW, while the WM-DLL350 model has a power consumption of 4.0KW. This is a significant difference, especially when it comes to energy efficiency and cost savings.

The machine's compressed air requirement is also an important factor. The WM-DLL160 and WM-DLL260 models require 0.45Mpa of compressed air, while the WM-DLL350 model also requires 0.45Mpa.
Here's a summary of the machine's compressed air requirements:
The machine's packaging width is also a crucial factor, especially when it comes to accommodating different product sizes. The WM-DLL160 model has a maximum packaging width of 160mm, while the WM-DLL350 model has a maximum packaging width of 350mm.
The machine's dimensions and weight are also worth noting. The WM-DLL160 model measures 1300×750×1900 mm and weighs 900kg, while the WM-DLL350 model measures 1600×950×1900 mm and weighs 1200kg.
In terms of speed, the machine can produce between 20-80 cycles per minute, depending on the model. The S-100 Automatic Blister Packing Machine, for example, can produce 80 packs per minute.
The machine's blister output is also an important factor, especially when it comes to meeting production demands. The S-100 Automatic Blister Packing Machine, for instance, can produce 80 packs per minute, each measuring 40mm x 100mm.
The machine's cooling water consumption is also worth noting. The S-300 Blister Machine, for example, requires 240 liters per hour of cooling water at 12°C.
A unique perspective: Packing List for Alaska

The machine's tooling and accessories can also affect its overall performance and efficiency. The S-300 Blister Machine, for example, comes with a weight of approximately 1850kg, including tooling.
In terms of air supply, the machine requires 90 psi and 14.2 SCFM of air. The ABM-I model, for example, requires 0.6-0.8MPa of air pressure.
The machine's power supply is also an important factor, especially when it comes to ensuring compatibility with different electrical systems. The ABM-I model, for example, can operate on either 110V 60Hz or 220V 50Hz power supply.
Product Features
These small blister pack machines are designed for economical smaller-batch production, making them perfect for businesses that need to produce a limited quantity of products.
They offer versatility in terms of packaging options, capable of thermoforming with and without plug assist or cold-forming. This flexibility allows you to choose the best method for your specific product.
The machines are also equipped with a servomotor-driven indexing system for fast and efficient production, and tool-less changeover for easy setup and minimal downtime.
Here are some key features to look out for in a small blister pack machine:
- Convenient sealing system
- Simple and intuitive operation
- Long service life with high-quality electrical heating bars
- Accurate temperature control
- Sufficient pressure for secure sealing
- Compact design with easy portability
- Optional steel stamp for printing production information
Features
The Argentecnica S-100 Blister Machine is a versatile and efficient packaging solution. It's capable of thermoforming with and without plug assist or cold-forming, making it suitable for a wide range of applications.
The machine's design allows for economical smaller-batch production, which is perfect for companies that need to package products in small quantities. Its servo-motor-driven indexing and tool-less changeover also enable fast production and minimal downtime.
One of the standout features of the S-100 is its intuitive interface. The machine is PLC controlled with a touch screen HMI and Ethernet connectivity, making it easy to set up and operate. This also means that recipes can be quickly loaded and changed, reducing production time.
The S-100 also offers an optional vision system for quality assurance. This feature ensures that products are packaged correctly and consistently, which is crucial for maintaining customer satisfaction.
Here are some of the technical specifications of the S-100:
The Argentecnica S-300 Blister Machine is another impressive packaging solution. It's capable of thermoforming with and without plug assist and cold-forming, similar to the S-100. However, it offers additional functionality with three, four, or five stations, including forming, sealing, code date, perforating, and die cutting.
The S-300 also features an optional vision system for quality assurance, ensuring that products are packaged correctly and consistently. This is a critical feature for maintaining customer satisfaction and reducing waste.
The S-300 is a more complex machine than the S-100, but it offers greater flexibility and customization options. Its ability to accommodate different stations and features makes it an ideal choice for companies with complex packaging needs.
9mm Round Tablet Sheet with 10 Holes
Our 9mm Round Tablet Sheet with 10 Holes is a high-quality product that's perfect for pharmaceutical applications. The sheet is made of hard or soft temper aluminum foil with a lacquer coating that helps in effective sealing.
This unique design allows for easy blister packing and storage. The aluminum foil is durable and resistant to corrosion.
The 10 holes on the sheet provide ample space for your tablets, making it easy to fill and pack. This design also ensures that the tablets are securely held in place.
The lacquer coating on the aluminum foil is designed to provide a tight seal, preventing moisture and air from entering the blister pack. This helps to maintain the integrity and potency of the tablets.
Ellipse Tablet

The Ellipse Tablet features an aluminum foil blister pack with a lacquer coating that helps seal the blisters effectively. This ensures the tablets stay fresh and secure.
The blisters are manufactured at an advanced production line, which speaks to the quality of the product.
The Ellipse Tablet blister pack is highly recommended for standard blister packs.
Product Specifications
The S-100 Automatic Blister Packing Machine stands at 55 inches high, 100 inches wide, and 25 inches deep, with a weight of approximately 900 kg, including tooling.
The machine requires a 220VAC, 3 phase, 50/60 Hz power supply and consumes approximately 4 KVA.
You can choose from three models of small blister packing machines: WM-DLL160, WM-DLL260, and WM-DLL350, each with varying capacities, power requirements, and sizes.
Here are some key specifications for each model:
The ABM-I model has a maximum heating area of 135*115mm and can heat up to 150℃ in 3-6 seconds.
S-300 Technical Specifications
The S-300 Blister Machine is a robust piece of equipment with some impressive technical specifications.

The machine operates at a maximum air pressure of 90 psi, with a flow rate of 14.2 SCFM.
It's also worth noting that the machine requires a significant amount of cooling water, with a consumption rate of 240 l/hr at 12C.
The S-300 Blister Machine is a substantial piece of equipment, weighing in at approximately 1850kg with tooling.
The machine is designed to handle a range of web materials, with the bottom web material capable of reaching a maximum width of 220 mm and a roll OD of 500 mm.
The top web material, on the other hand, has a maximum width of 215 mm and a roll maximum OD of 200 mm.
The forming area of the machine is relatively compact, measuring 210 mm x 155 mm max.
The machine is also capable of forming to a depth of 16 mm max, although this can be increased to 23 mm on request.
In terms of speed, the S-300 Blister Machine can operate at a rate of 15-60 cycles/min.
The machine's index is also noteworthy, with a maximum measurement of 165 mm.
Specifications

The S-100 Automatic Blister Packing Machine is a 220VAC, 3 phase, 50/60 Hz electric machine that consumes approximately 4 KVA of power. It stands 55 inches high, 100 inches wide, and 25 inches deep, and weighs around 900 kg with tooling.
The machine has a forming area of 80 mm x 130 mm max and can form blisters up to 12 mm deep. It can produce 80 packs per minute, with each pack measuring 40 mm x 100 mm.
The S-300 Blister Machine, on the other hand, is an air-powered machine that operates at 90 psi and 14.2 SCFM. It consumes 240 liters of cooling water per hour at 12°C.
Here's a comparison of the two machines:
The ABM-I machine has a maximum heating area of 135*115mm, a heating temperature range of 90-150℃, and a heating time of 3-6 seconds. It requires an air pressure of 0.6-0.8MPa and has an air displacement of 0.12m³/min. It weighs 21 kg and measures 320*300*375mm.
The WM-DLL160, WM-DLL260, and WM-DLL350 machines have capacities of 20000-50000pces/h, 30000-60000pces/h, and 50000-90000pces/h, respectively. They all require 380V power and consume 2.75KW, 3.75KW, and 4.0KW of power, respectively.
Size 0 Capsule Sheet
The Size 0 Capsule Sheet is a versatile option for standard blister packs. It's manufactured at an advanced production line.
The blisters are made using hard or soft temper aluminum foil. This type of material is ideal for effective sealing.
A lacquer coating is applied to the aluminum foil, which helps ensure the blisters seal properly. This coating is a key factor in maintaining the integrity of the packaging.
The Size 0 Capsule Sheet is highly recommended for standard blister packs.
Packaging Options
When choosing a small blister pack machine, consider the type of packaging you need.
With a small blister pack machine, you can create rectangular blister packs with a maximum size of 120mm x 70mm x 20mm.
The machine can produce 20-40 blister packs per minute, making it suitable for small to medium-sized productions.
This speed is ideal for producing small quantities of products, such as samples or test runs.
You can also choose from various blister pack sizes, including 50mm x 50mm and 80mm x 40mm.
These smaller pack sizes are perfect for packaging small items like pills, vitamins, or cosmetics.
The machine can handle a wide range of blister pack materials, including PVC, PET, and ALU.
These materials are commonly used in the pharmaceutical, cosmetic, and food industries.
The small blister pack machine is designed for easy cleaning and maintenance, making it a great choice for high-volume productions.
This feature reduces downtime and ensures the machine runs smoothly and efficiently.
Frequently Asked Questions
What machine is used to make blister packaging?
The DPP-140 is a machine used to create flat-type aluminum-plastic blister packaging. It integrates various functions, including PVC feeding and sealing, to produce high-quality blister packs.
What is the alternative to blister packs?
Paperform is a curbside-recyclable alternative to traditional blister packs, made from sustainable paperboard. This eco-friendly packaging solution is a responsible choice for customers and the environment.
