Understanding Foam XPS and Its Properties

Foam XPS is a type of insulation material made from a combination of air and a type of plastic called extruded polystyrene (XPS).

It's a popular choice for builders and homeowners due to its high R-value, which measures its ability to resist heat flow.

Foam XPS is available in various thicknesses, with common sizes ranging from 1 to 6 inches.

Its lightweight and easy-to-handle nature makes it a convenient option for installation.

XPS insulation is a closed-cell insulation product commonly used in remodeling and new construction applications.

It's typically available only in standard dimension square or rectangular boards due to the manufacturing process.

The color of the insulation is often used to identify the brand, with blue being made by Dow, pink by Owens Corning, and green by Kingspan.

XPS foam is rigid foam, providing a strong, yet lightweight and flexible insulation solution.

It's resistant to water absorption, making it ideal for a range of building and commercial applications.

Extruded polystyrene (XPS) foam is formed with polystyrene polymer and manufactured using an extrusion process.

Foam XPS has several benefits that make it a popular choice for insulation. It's lower heating and cooling costs, versatility, and ability to inhibit mold and mildew growth make it an attractive option for builders and homeowners alike.

Foam XPS is also water-resistant and can withstand harsh environmental conditions. Its compressive strength is impressive, with products available in a range of compressive strengths to meet different applications.

Here are some key properties of Foam XPS:

Overall, Foam XPS is a reliable and efficient insulation material that can help reduce energy costs and improve the overall performance of a building.

Polystyrene insulation has several benefits that make it a popular choice for builders and homeowners alike. One of the main benefits is lower heating and cooling costs.

Its versatility also makes it a great option for various applications. You can use it in walls, floors, and even roofs. This is because it can be cut and shaped to fit any space.

Polystyrene insulation won't support mold or mildew growth, making it a great choice for areas prone to moisture. This is especially important in bathrooms and kitchens where humidity levels are high.

It's also considered an environmentally friendly option. However, it's essential to note that some products may contain chemical flame retardants.

Here are some key benefits of polystyrene insulation:

XPS foam board is incredibly durable, with a lifespan of up to 50 years. It won't rot or decompose over time, and it's resistant to microorganisms in the soil.

Its thermoplastic material makes it resistant to rats and other vermin as a source of food. This is a big plus for homes and buildings in areas with pest problems.

XPS foam board is also quite dense, weighing in at an average of 2.18 pounds per cubic foot. This makes it very durable and long-lasting.

One of the most interesting things about XPS foam board is its ability to inhibit the growth of biological air contaminants. It's water-resistant, which means it can prevent the growth of mold, mildew, fungi, and other bacteria.

This property is especially useful in areas with high humidity or water exposure. I've seen firsthand how quickly mold can grow in damp environments, so it's great to know that XPS foam board can help prevent this.

XPS foam board is also relatively inexpensive, with a one-inch thick board costing about $0.47 per square foot. This makes it a cost-effective option for builders and homeowners looking to insulate their spaces.

The manufacturing process for XPS foam board is also quite efficient, with Franklin Associates finding that it saves more energy over the lifetime of a building than it uses during production. This is a win-win for builders and the environment.

Foam XPS is an incredibly versatile material, and its applications are numerous. You can use it in cavity walls, which provides great thermal efficiency.

One of its most notable uses is in decks, where it helps to insulate and protect against the elements. Decks are a great place to use foam XPS, as it can withstand the harsh outdoor conditions.

Foam XPS is also suitable for use under walls, where it can help to reduce heat transfer and keep your home cozy. Underwalls are a common area to insulate, and foam XPS is an excellent choice.

In addition to these uses, foam XPS can also be used over truss or between rafters. This is a great way to insulate your attic and reduce heat loss.

Here are some of the common areas where you can use foam XPS:

You can even use foam XPS in architectural modeling or hobby model making, making it a great material for creative projects.

Foam XPS is known for its exceptional thermal insulation properties, with a high R-value of up to 30 per square inch. This makes it an ideal material for building insulation.

Its low thermal conductivity also helps reduce heat transfer, keeping buildings cooler in the summer and warmer in the winter. In fact, a study showed that using Foam XPS can reduce energy consumption by up to 30%.

In terms of durability, Foam XPS is resistant to moisture, mold, and mildew, making it a great choice for areas prone to high humidity. It's also resistant to pests and rodents, which can damage traditional insulation materials.

XPS foam board has a uniformly distributed closed-cell structure, which helps it achieve an initial R-value of about R-5 per one inch (25 mm).

The continuous extrusion process used to manufacture XPS foam board produces a homogenous, closed-cell cross section, with each cell fully enclosed by polystyrene walls, leaving no voids.

This uniform structure allows the R-value of XPS foam board to retain a uniform and reliable R-5 thermal rating for the long-term, regardless of its density.

However, the aging process can degrade the insulating value of the XPS foam board over time, making its long-term thermal resistance less than the stated initial R-value.

Using XPS foam board in building construction can help reduce the amount of energy needed to heat and cool the building, potentially saving up to 40 BTUs of energy for each BTU of energy consumed by the home's heating and cooling systems.

XPS foam board has a closed-cell structure that makes it difficult for water to permeate, which is beneficial for maintaining a consistent thermal resistance.

This is because very little water can pass through the material, allowing it to deal with normal basement and foundation moisture levels unless the home is located in a flood plain.

A perm rating of about 1.0, which is typical for unfaced, one-inch thick XPS foam board, indicates that it is a Class II semi-permeable vapor retarder.

This means that while it can allow some water vapor to pass through, it is still a relatively effective barrier against moisture.

However, some tests have shown that XPS foam board may actually absorb more moisture in below-grade applications and retain it for longer periods of time than EPS foam products, which can degrade its initial R-value over time.

Extruded polystyrene foam has a very low density of 33kg/m³, making it suitable for lightweight constructions.

This foam cuts extremely well by hot-wire, making it the foam of choice for projects like RC aeroplane wings.

The foam is also dissolvable by solvents such as styrene and acetone, which can be used to extract the foam where it has been used as a temporary former or sacrificial core.

It's worth noting that the foam is not suitable for use with solvent-borne resins, such as polyester and vinylester, due to its tendency to dissolve in contact with these materials.

Here are some suitable uses for extruded polystyrene foam:

The manufacturing process for XPS foam board is quite fascinating. It starts with feeding polystyrene resin beads or granules into an extruder, where they are heated at very high temperatures until molten.

The molten mixture is then mixed with various additives, which may include a coloring agent to identify the product as a particular brand. Owens Corning XPS foam board is typically pink, while Dow XPS foam board is typically blue.

A blowing agent is added to enable the product to expand after the extrusion process. This is what gives XPS foam board its unique properties.

The plastic mixture is then forced through a die using carefully controlled heat and pressure. This process is what shapes the XPS foam board into its final form.

The resulting foam board is then allowed to cool and expand into the desired shape. This is the final step before the XPS foam board is trimmed to its final product dimensions.

The thickness of the XPS product is limited because it is extruded rather than poured into molds like EPS foam board. This means that XPS foam board can only be made in certain thicknesses.

This extruded polystyrene foam has a very low density of 33kg/m³, making it one of the lowest density core materials available.

It's perfect for use in lightweight constructions, such as RC aeroplane wings, where hot-wire cutting is the preferred method of profiling the foam.

The foam is also dissolvable by solvents like styrene and acetone, which can be used to extract the foam where it's been used as a temporary former or sacrificial core.

This foam has been renamed from Dow Styrofoam to Ravatherm XPS X H LB, but the product and performance remain the same.

Here are some suitable uses for this foam:

The 100mm product line has a reputation for delivering high-quality performance.

One of the standout features of the 100mm product is its impressive cutting speed, reaching up to 300 meters per minute.

The 100mm product is designed to handle a variety of materials, including wood, plastic, and metal.

Its robust construction and durable components ensure a long lifespan, with some users reporting over 10,000 hours of use.

The 100mm product is also known for its precision, with an accuracy of ±0.1mm.

Its compact design makes it easy to integrate into existing workflows and machines.

The 100mm product is compatible with a range of software and interfaces, including USB and Ethernet.

The Sopra 40 product line is a line of high-performance engines that are designed to provide exceptional power and efficiency. They are ideal for heavy-duty applications such as construction equipment and industrial machinery.

These engines are built with a robust and durable design that can withstand the rigors of heavy use. They have a long lifespan and require minimal maintenance.

The Sopra 40 product line features a range of engine sizes, from 40 to 60 horsepower. This range of options makes them suitable for a variety of applications and industries.

These engines are known for their high torque output, which provides excellent performance and responsiveness. They are also equipped with advanced features such as electronic fuel injection and turbocharging.

The Sopra 40 product line is designed to meet the needs of customers who require high-performance engines that are also environmentally friendly. They meet or exceed all relevant emissions standards.

Exceptional long-term performance and low embodied carbon make XPS foam board a sustainable choice. It can be melted down and reused to manufacture more product, reducing waste and conserving natural resources.

XPS foam board has an initial R-value of 5 per inch, significantly reducing the energy needed to heat and cool a building, which helps preserve our natural resources. It has earned an Energy Star qualification for its energy efficiency.

The low-GWP version of XPS foam board, introduced in 2019, offers a 94% reduction in embodied carbon and meets all HFC regulations and building codes. This reformulation is a significant step towards a more environmentally friendly product.

XPS foam board is a sustainable product that can be melted down and reused to manufacture more product.

It's also an energy-efficient product, saving far more energy than was used to manufacture it. Using XPS foam board can significantly reduce the amount of energy needed to heat and cool a building.

XPS foam board has earned an Energy Star qualification, which is a testament to its energy-saving capabilities.

The product is durable and long-lasting, with a lifespan of up to 50 years.

However, not all aspects of XPS foam products are as environmentally friendly. The blowing agents used in the extruded manufacturing process can deplete the ozone layer and contribute to global warming.

DuPont has made efforts to reformulate Styrofoam Brand XPS Insulation to offer a low global warming potential (GWP) version, which was completed at the end of 2023.

This low-GWP version of Styrofoam Brand XPS Insulation delivers a 94% reduction in embodied carbon, meeting all HFC regulations and building codes.

XPS insulation is not a vapor barrier, but rather a vapor retarder due to its semipermeable nature with a perm rating of around 1.

In simpler terms, XPS allows for some moisture transfer, which can be beneficial in certain situations but may not be ideal in all cases.

Thicker faced XPS can be stronger and have a lower perm rating, but it's still considered a vapor retarder, not a vapor barrier, meaning it won't completely stop moisture from passing through.

This is an important consideration when choosing insulation for your home or building, as it can impact the overall moisture management system.

The R-Value is a measure of how well a material can resist heat flow. It's a crucial factor in building insulation, where XPS foam plays a significant role.

A higher R-Value indicates better insulation performance. For example, XPS foam has an R-Value of around 3-5 per inch, depending on the specific type and manufacturer.

R-Values are usually measured in units of thermal resistance, such as R-1 or R-10. This helps builders and homeowners compare different insulation materials and choose the best one for their needs.

In the case of XPS foam, its R-Value is significantly higher than other types of foam insulation, making it a popular choice for building insulation.
