Tuck Under Liftgate Options and Selection Guide

Tuck under liftgates are a popular option for businesses and individuals alike, offering a convenient and cost-effective way to load and unload heavy packages and equipment.

A tuck under liftgate can be installed on a variety of vehicles, including vans, trucks, and SUVs, and can be customized to fit specific needs.

The liftgate's height can range from 40 to 72 inches, with some models offering a 90-degree lift for easy loading and unloading.

For businesses that need to transport heavy equipment, a tuck under liftgate with a 4000-pound capacity is a good option, while smaller businesses may prefer a 2000-pound capacity model.

For more insights, see: Liftgate Weight Capacity

A lift gate is a type of gate designed to be used on trucks and trailers to load and unload heavy objects.

It's a crucial piece of equipment for many industries, including logistics and construction, where large and heavy items need to be transported.

Lift gates come in different designs, but one popular type is the tuck under lift gate, also known as a Tuckaway or Flipaway style.

This design allows the lift gate to fold and tuck under the rear of the truck or trailer when not in use, providing clear access to the cargo area.

The tuck under lift gate is particularly useful in urban delivery scenarios, where space is limited and maneuverability is crucial.

It minimizes the risk of damage when the lift gate is not deployed, making it a practical choice for many applications.

Consider reading: Liftgate Not Working

A tuck under liftgate is designed to fold and tuck under the rear of a truck or trailer when not in use, providing clear access to the cargo area and minimizing damage risk.

The tuck-under liftgate is particularly popular in urban delivery scenarios where space is limited and maneuverability is crucial. Its compact design makes it a great choice for navigating tight spaces.

Some key features of our tuckaway liftgates include optional extruded aluminum or galvanized steel platforms, which offer a reliable surface for loading and unloading. We also offer pallet-sized loads, making our liftgates perfect for diverse applications.

Here are some of the key features of our tuckaway liftgates:

The TKL features of the Tommy Gate Tuckunder Series liftgate are quite impressive. It's designed to be low in profile, making it easy to store underneath a vehicle bed. The liftgate is also lightweight and durable.

One of the standout features of the TKL is its power-down design, which provides quick and consistent platform deployment. This is especially useful in busy work environments where time is of the essence.

Here are some of the key features of the TKL:

As you can see, the TKL has a range of features that make it a reliable and efficient choice for liftgate needs.

Liftgates are designed to handle a variety of loads, including pallet-sized ones.

You can choose from an optional extruded aluminum platform or a galvanized steel platform, both of which are durable and reliable.

A liftgate's platform depth is crucial to keep products secure while in use.

The platform depth can usually be chosen based on the product's size and weight.

You can opt for an aluminum or steel platform, with steel being more popular and inexpensive, but aluminum having a longer lifespan due to its resistance to corrosion.

Here are some key features to consider:

A cab cut-off switch is an important safety feature that prevents unauthorized use of the liftgate.

Handheld remotes also make it easier for operators to use the liftgate when loading and unloading products from the rear of the truck body.

When working with flatbed and van lift gates, it's essential to understand the different body styles and order codes available.

The Tuckunder Series: TKL offers a range of options, including a 102" wide body and a 96" wide body.

If you're looking for a lift gate with a 102" wide body, the order code is 010 #2338, and it corresponds to body style A.

For a lift gate with a 96" wide body, the order code is 020 #2144, and it corresponds to body style B.

If you're considering adding 18-inch fixed side steps to your lift gate, keep in mind that they're only available on bed heights between 33 to 39 inches.

Here's a quick reference table for the Tuckunder Series: TKL order codes and body styles:

Choosing a liftgate that meets your needs is crucial for safe and efficient operations.

Consider the weight capacity of the liftgate, which varies by model. Ensure the model you choose can handle the maximum load you plan to transport, and add a margin of safety to prevent overloading.

The size of the liftgate platform should accommodate the dimensions of the cargo you typically move. Larger platforms provide more flexibility but may require more space when deployed.

When it comes to material and durability, aluminum liftgates are a good option for corrosion resistance, especially in colder states. Steel liftgates, on the other hand, are more popular and inexpensive.

Here are some key factors to consider when selecting a liftgate:

Choosing the right liftgate for your needs is crucial to ensure safe and efficient loading and unloading of cargo. A liftgate's weight capacity is a top priority, so make sure to choose one that can handle the maximum load you plan to transport.

A margin of safety is also essential, so consider getting the next level up to avoid overloading and premature part failure. For example, if a customer needs to load up to 2500lbs, it's recommended to get a liftgate with a 3000lbs capacity.

The size of the liftgate platform is also vital, as it needs to accommodate the dimensions of the cargo you typically move. Larger platforms provide more flexibility but may require more space when deployed.

Liftgates are made from various materials, including steel and aluminum. Aluminum liftgates are preferred in colder states due to their corrosion resistance.

Recommended read: Lift Gate Capacity

Here are some key factors to consider when selecting a liftgate:

A cab cut-off switch and handheld remotes are also important safety options to consider, as they prevent unauthorized use of the liftgate and enable convenient operation.

Choosing the right parts for your liftgate is crucial to ensure compatibility and optimal performance. OEM parts meet the manufacturer's specifications.

Partnering with a reliable liftgate parts distributor guarantees access to top-quality components. This is key to getting the best results from your liftgate.

Check this out: Box Truck Liftgate Parts

The weight capacity of a liftgate is a crucial factor to consider, and it's essential to choose a model that can handle the maximum load you plan to transport. A good rule of thumb is to get the next level up from what you need, to ensure the gate is never overloaded or overworked.

Liftgates come in various materials, including steel and aluminum, each with its own advantages. Aluminum liftgates are preferred in colder states due to their corrosion resistance.

Here are some top manufacturers of tuck under liftgates, known for their high-quality and durability:

These manufacturers offer a range of features and options, including extruded aluminum platforms, galvanized steel platforms, and pallet-sized loads.

The liftgate is a critical component of a forklift, consisting of a hydraulic cylinder, a ram, and a carriage, which work together to lift and lower loads.

The hydraulic cylinder is a key part of the liftgate, converting hydraulic pressure into mechanical motion to lift and lower loads safely and efficiently.

A liftgate's carriage is designed to move up and down, allowing it to reach different heights and accommodate a variety of load sizes.

The liftgate's ram is a critical component, responsible for transferring the force generated by the hydraulic cylinder to the carriage, allowing it to move up and down.

The liftgate's carriage is typically made of high-strength steel, ensuring it can withstand the stresses and strains of daily use.

Some liftgates also feature a mechanical or hydraulic overload protection system to prevent damage in case of an overload.

For another approach, see: Liftgate Hydraulic Cylinder

Maxon is a leading manufacturer of liftgates, and their Tuk-A-Way series is highly regarded for its durability and performance.

The Tuk-A-Way series comes in various weight capacities and platform sizes to suit different needs. This flexibility makes them a popular choice in the logistics industry.

Waltco tuck under liftgates are known as Flipaway models, and they're lightweight and strong. They're designed for ease of installation and maintenance, providing excellent value for money.

Anthony Liftgates offers a range of tuckunder models known for their reliability and ease of use. These models provide excellent lifting capacities and robust construction, making them a popular choice in the logistics industry.

Palfinger, a global leader in lifting solutions, offers a variety of tuck under liftgates known as folding liftgates. These models are engineered for durability and ease of operation, making them a preferred choice for many businesses.

Here are some top manufacturer models to consider:

When selecting a tuck under liftgate, you need to consider a few key factors to ensure you get the right one for your needs.

Weight capacity is crucial, and it's essential to add a margin of safety to avoid overloading the gate. For example, if a customer needs to load up to 2500lbs, it's recommended to get a gate with a 3000lbs capacity to ensure safe operation.

The size of the liftgate platform should accommodate the dimensions of the cargo you typically move. A larger platform provides more flexibility but may require more space when deployed.

Material and durability are also important considerations. Aluminum liftgates are preferred in colder states due to their corrosion resistance, while steel liftgates are more popular and inexpensive.

Here are some key considerations to keep in mind:

When shopping for a liftgate, it's essential to consider the advantages they offer. A well-designed liftgate can make a huge difference in your daily operations.

The tuckunder series of liftgates is renowned for its consistent lifting action and ease of use. Its wide arm design ensures stability and balance during operation, which is a game-changer for heavy loads.

Self-leveling mechanisms are a must-have in liftgates. The tuckunder series' self-leveling mechanism adjusts to maintain a level platform, enhancing safety and efficiency.

Accommodating various bed heights is crucial for adaptability. The tuckunder series is designed to fit different bed height options, making them adaptable to various trucks.

Some liftgates are more versatile than others. The tuckunder series' ability to accommodate various bed heights makes it a top choice for businesses that need to switch between different trucks or trailers.

When selecting a liftgate, weight capacity is a crucial factor to consider. Ensure the model you choose can handle the maximum load you plan to transport, and add a margin of safety to prevent overloading and premature part failure.

A larger platform size can provide more flexibility, but may require more space when deployed. Consider the dimensions of the cargo you typically move to determine the ideal platform size.

Liftgates are made from various materials, including steel and aluminum. Aluminum liftgates are preferred in colder states where corrosion resistance is essential.

To choose the right tuckaway liftgate, you'll need to answer two main questions: what is the maximum weight that will go on the liftgate platform and how deep of a platform is needed? A 3000lb tuckaway liftgate is not designed to lift 3000lb unless the weight is spread evenly over the entire platform.

Here are some key features to consider when selecting a tuckaway liftgate:

A cab cut-off switch located in the cab of the vehicle is an important safety option, preventing unauthorized use of the liftgate. Hand-held remotes enable the operator to use the liftgate more conveniently when loading and unloading the product from the rear of the truck body.

The capacity of a tuck under liftgate is a crucial factor to consider when selecting the right one for your needs. It varies depending on the model and manufacturer, but generally ranges from 2,000 to 6,000 pounds.

To ensure safe and efficient loading and unloading, it's essential to choose a liftgate with a capacity that can handle the maximum load you plan to transport. Don't forget to add a margin of safety to prevent overloading and premature part failure.

For example, if you need to load up to 2,500 pounds, consider getting a liftgate with a capacity of 3,000 pounds. This will give you a bit of extra leeway and help extend the lifespan of your liftgate.

Here's a rough guide to help you choose the right capacity:

Remember, it's always better to err on the side of caution and choose a liftgate with a higher capacity than you think you'll need. This will help ensure safe and efficient operations, and prevent premature wear and tear on your equipment.

Tommy Gate has released a brand-new Tuckunder Series liftgate, the TKT Models, which are the first Tuckunder-style liftgates ever produced by the company.

The TKT Models feature a state-of-the-art, wide-arm, dual-cylinder design to maximize convenience for operators and upfitters.

These models are offered with self-leveling, wedge-style platforms in either extruded aluminum or steel treadplate, lifting capacities of 2500 or 3000 lbs., and bed extensions fitting either 96- or 102-inch-wide bodies.

Some notable features of the TKT Models include hydraulic power-down for quick platform deployment, an underride impact guard for protection, and 24-inch rubber dock bumpers to prevent damage.

The TKT Models also come with a snubber kit to secure the stored platform and a low-profile, fixed toggle control with a five-minute inactivity shut off.

Tommy Gate's Senior Engineer Andrew Fitzgibbon explained the development process, stating that the company interviewed distributors, installers, and end customers to gather feedback and inform the design of the TKT Models.

The TKT Models are available for purchase on the Tommy Gate website, and development and operational videos can be viewed on the Tommy Gate YouTube Channel.

If you're interested in purchasing a TKT Model or learning more about its features, you can find a distributor using Tommy Gate's Distributor Locator or email [email protected] for more information.
