The Floating Harbour is a marvel of engineering that has been in operation since the 19th century. It was designed to allow ships to dock and unload cargo while remaining afloat.

The harbour's innovative design made it possible to reduce the need for expensive and labor-intensive land-based infrastructure. This was a game-changer for the city's economy.

The harbour's construction began in 1842, and it was officially opened in 1849. It was a major undertaking that required significant resources and manpower.

The Floating Harbour has undergone several renovations and expansions over the years, with the most significant being the installation of a new lock system in the late 19th century.

History and Purpose

The Floating Harbour was created to solve a major problem for visiting ships. The River Avon's massive tidal range of up to 12 metres made it difficult for ships to navigate and avoid getting stranded on the mud.

The harbour's purpose was to provide a safe and stable docking area for ships. This was crucial as Bristol's popularity as a cargo destination increased in the mid 1700s, making it essential for the Port of Bristol to stay competitive.

The harbour's unique design was a solution to the challenges posed by the River Avon's tidal range.

Why Was It Created?

A Boat Tied to the Dock
Credit: pexels.com, A Boat Tied to the Dock

The Port of Bristol was created to address a significant problem caused by the tidal range of the River Avon, which can change by as much as 12 metres at certain times of the year.

This tidal range made it difficult for visiting ships to navigate the harbour, as they could end up stranded on the thick mud of the Avon if they didn't time their trip well.

The Port of Bristol needed to find a solution to stay competitive as Bristol's popularity as a cargo destination increased in the mid 1700s.

The city's unique geography posed a challenge, but it also presented an opportunity for innovation and development.

Brunel and the Harbor

Brunel and the Harbor was a pivotal partnership that transformed the way goods were transported in Bristol. Isambard Kingdom Brunel, a renowned engineer, worked closely with the Bristol Port and Harbour Trust to design and build a series of docks and warehouses.

Credit: youtube.com, The First Industrial Scale Marine Building | Brunel: Building a Great Britain | BBC Select

The SS Great Britain, a ship designed by Brunel, was a game-changer for the harbor, allowing for the transportation of larger volumes of goods more efficiently. It was a massive ship for its time, measuring 322 feet in length.

Brunel's innovative approach to harbor design included the creation of a dock system that could accommodate the SS Great Britain and other large vessels. This led to a significant increase in trade and commerce in the area.

The harbor's transformation under Brunel's guidance also included the construction of new warehouses and storage facilities, which helped to streamline the process of loading and unloading goods.

Design and Construction

The design and construction of a floating harbour is a remarkable feat of engineering. The first plans for a system to overcome the tidal range in the harbour were created by engineer John Smeaton in 1765.

Construction on the Floating Harbour started in May 1804 and was completed in May 1809. The harbour covers an area of 70 acres, including the locks and weirs at Hotwells and Netham.

Credit: youtube.com, Bristol Harbour Floating Bridge (University of Southampton - Group Design Project)

William Jessop's final plan involved a lock system extending from Hotwells in the west to Netham Lock in the east, a distance of roughly 3.5 miles. This innovative design allowed for a stable water level and current in the harbour, making it safe for boats and a flood defence for the city.

Design and Construction

The first plans for a system to overcome the tidal range in the harbour were created by engineer John Smeaton in 1765.

William Jessop's final plan for the Floating Harbour involved a lock system extending from Hotwells in the west to Netham Lock in the east, a distance of roughly 3.5 miles.

Construction on the Floating Harbour started in May 1804 and was completed in May 1809, a significant milestone in the history of Bristol's harbour.

The harbour covers an area of 70 acres, including the locks and weirs at Hotwells and Netham, Cumberland Basin, the Feeder Canal, and the New Cut, which diverts the tidal water away from the harbour.

Credit: youtube.com, Design and Construction Process Part 1 Design Process

William Jessop's design merged the best ideas from earlier proposals, and his final plan was accepted in 1803 after several engineers had suggested solutions earlier.

The Floating Harbour was the largest artificially enclosed stretch of water in the world when it opened on 1 May 1809, a testament to the ingenuity of its designers.

In the 1830s, Isambard Kingdom Brunel revised the design by replacing the 'overfall' weir with 'underfall' sluices to solve the problem of silt build up.

Spike Island, a piece of land situated between the Cut to the south, and the Floating Harbour to the north, was created as part of Jessop's design and remained a true island until the Second World War.

Underfall Yard

Underfall Yard was a crucial part of the Floating Harbour's design and construction, addressing the issue of surplus water in the harbour.

The original engineer William Jessop created the Overfall Dam, but by the 1830s, silt was building up in the harbour. This led to the need for a new solution.

Aerial photo of a construction site on a coastal pier with clear turquoise waters.
Credit: pexels.com, Aerial photo of a construction site on a coastal pier with clear turquoise waters.

Isambard Kingdom Brunel designed three shallow sluices and one deep scouring sluice between the harbour and the New Cut to address the problem. These sluices were a game-changer for the harbour's water management.

The shallow sluices allowed for adjustment of the dock water level according to weather conditions. This was a clever touch, considering the harbour's exposed location.

A drag boat would scrape the silt away from the quay walls, making room for new water to flow in. This was a labor-intensive process, but it was essential for keeping the harbour clear.

The deep sluice opened at low tide, creating a powerful undertow that sucked the silt into the river. This allowed the silt to be carried away on the next tide, keeping the harbour clean.

Several old buildings at Underfall Yard date from the 1880s and have listed building status. This is a testament to the harbour's rich history and the importance of preserving its architectural heritage.

The octagonal brick and terracotta chimney of the hydraulic engine house dates from 1888 and is grade II* listed, as is the hydraulic engine house itself.

Impounding

Credit: youtube.com, Impoundment Construction and Management (Episode 21)

Floating docks are generally maintained at a level at least as high as the highest tide. This requires a supply of water, which can come from a river flowing into the harbour, as was the case for Bristol initially with the River Frome.

In some cases, a mechanical pumping or impounding station is constructed to maintain the higher level. Liverpool's northern docks, for example, were served by an impounding station at Huskisson Dock and one on the opposite side of the Mersey for Wallasey Dock.

Bow Locks in East London uses a bi-directional system since the year 2000, permitting boats to transfer between the tidal Bow Creek and Limehouse Cut. The operation of Bow Locks is tightly controlled by the duty lock-keeper as every tide is different.

In general, maintaining a higher level in a floating dock requires a reliable source of water. This can be achieved through a river source or an impounding station, as seen in the examples of Bristol and Liverpool's northern docks.

Credit: youtube.com, Portadam Impoundment Systems

Here are some key types of docks and their characteristics:

  • Branch dock: a continuous basin within a dock, providing greater wharf frontage.
  • Half tide dock: a simpler version, where a fixed sill retains some water within the dock to allow ships to float, but at varying height.

Where the dock is lower than the tide, other forms of lock gate must be used, such as caissons.

Frequently Asked Questions

How does Bristol Floating Harbor work?

Bristol Floating Harbor allows ships to safely enter the harbor by using a system of locks that adjust to the rising tide. The locks enable ships to move from the basin to the harbor through the Junction Lock.

What is a floating dock called?

A floating dock is also known as a floating pier or floating jetty. It's a platform supported by pontoons, often connected to the shore with a gangway.
